Place of Origin:
China
Brand Name:
New Gonow
Model Number:
HU01
Long Endurance High Capacity Logistic Van Electric Cargo Van Electric Logistics Vehicle Bus
Configuration:
|
Items Electric Cargo Van |
HU01 (7m3 Logistics vehicle)- standard model |
HU01 (7m3 Logistics vehicle)- Logistics links model |
HU01 (7m3 Logistics vehicle)- EU version |
|||
|
Basic parameters |
Overall dimensions |
Length(mm) |
5428 |
|||
|
Width(mm) |
1780 |
|||||
|
Height(mm) |
1950 |
|||||
|
Front suspension(mm) |
798 |
|||||
|
Rear suspension(mm) |
1280 |
|||||
|
Wheel base(mm) |
3350 |
|||||
|
Front track width(mm) |
1558 |
|||||
|
Rear track width(mm) |
1565 |
|||||
|
Container size |
Internal length(mm) |
3010 |
||||
|
Inside width(mm) |
1710 |
|||||
|
Inner height(mm) |
1400 |
|||||
|
Container volume(m³) |
7.2 |
|||||
|
Quality parameters |
Unladen mass (kg) |
1445 |
1470 |
1470 |
||
|
Servicing front axle load (kg) |
850 |
890 |
890 |
|||
|
Rear servicing axle load (kg) |
595 |
580 |
580 |
|||
|
Rated load mass (kg) |
1235 |
1210 |
1210 |
|||
|
Full load mass (kg) |
2810 |
|||||
|
Full load front axle load (kg) |
1150 |
|||||
|
Axle load after full load (kg) |
1660 |
|||||
|
Performance parameters |
30min maximum stable speed (km/h) |
≥85 |
||||
|
1km maximum instantaneous speed (km/h) |
≥90 |
|||||
|
0~50km/h acceleration time (s) |
≤6 |
|||||
|
50~80km/h acceleration time (s) |
≤10 |
|||||
|
Maximum gradient |
≥20% |
|||||
|
Energy consumption (Ekg) (Wh/km. kg) |
≤0.28 |
|||||
|
New energy system |
Battery |
Battery type |
Lithium iron phosphate |
|||
|
Battery manufacturer |
Hengtian Gotion |
CATL |
CATL |
|||
|
Power (kWh) |
41.93 |
50.23 |
50.23 |
|||
|
Voltage level (V) |
332.8 |
334.88 |
334.88 |
|||
|
Energy density (Wh/kg) |
≥135 |
|||||
|
Battery pack cooling mode |
Natural cooling |
|||||
|
Battery electric heating |
● |
|||||
|
Motor |
Motor type |
Permanent magnet synchronous motor |
||||
|
Motor rated/peak power (kW) |
35/70 |
|||||
|
Motor rated/peak torque (N.m) |
80/190 |
|||||
|
Motor rated/peak speed (rpm) |
4178/10000 |
|||||
|
Motor cooling mode |
water-cooling |
|||||
|
Charging mode |
Quick charge |
●(China standard) |
●(European Standard) |
|||
|
Slow charge |
●(China standard) |
●(European Standard) |
||||
|
Slow charging gun |
○(Portable AC charging gun - China standard) |
○(European Standard) |
||||
|
Fast charging time (h) (30%~80%) |
≤1 |
|||||
|
Slow charging time (h) (20%~100%) |
≤13.5 |
|||||
Integrated electric drive
