Place of Origin:
China
Brand Name:
New Gonow
Model Number:
HM01
New Energy 6m³ Logistics Vehicle with Strong Endurance Electric Cargo Van for Urban and City Transportation
Data sheet:
|
Models |
Tianjin Lishen version |
Gotion version |
||||
|
Model No. |
NGA5030XXYBEV2 |
NGA5030XXYBEV3 |
||||
|
Basic parameters |
Overall dimensions(mm) |
4865×1715×2060 |
4865×1715×2060 |
|||
|
Curb weight (kg) |
1620 |
1590 |
||||
|
Total mass (kg) |
3150 |
3150 |
||||
|
Load capacity (including people) (kg) |
1530 |
1560 |
||||
|
Seats |
2 |
2 |
||||
|
1km maximum speed (km/h) |
95 |
95 |
||||
|
30min maximum stable speed (km/h) |
90 |
90 |
||||
|
Maximum gradient |
20% |
20% |
||||
|
Range (NEDC) (km) (HICONICS motor) |
≥260 |
≥220 |
||||
|
Cargo box volume (m3) |
≥5.4 |
≥5.4 |
||||
|
New energy system |
Battery |
Battery type |
Lithium iron phosphate |
Lithium iron phosphate |
||
|
Battery brand |
Tianjin Lishen |
Hengtian Gotion |
||||
|
Total battery energy (kWh) |
41.6 |
41.93 |
||||
|
Battery density (Wh/kg) |
≥135 |
≥135 |
||||
|
Battery cooling mode |
Natural cooling |
Natural cooling |
||||
|
Electric heating |
● |
● |
||||
|
Drive motor |
Motor brand |
HICONICS○ |
Oswell● |
Oswell● |
LINCONTROL○ |
|
|
Motor type |
Permanent magnet synchronization |
Permanent magnet synchronization |
Permanent magnet synchronization |
|||
|
Motor rated/peak power (kW) |
30/60 |
30/60 |
30/60 |
30/70 |
||
|
Peak torque (N.m) |
225 |
220 |
220 |
230 |
||
|
Motor cooling mode |
Liquid cooling |
Liquid cooling |
Liquid cooling |
|||
|
Charging mode |
Quick charge |
● |
● |
|||
|
Slow charge |
● |
● |
||||
|
Slow charging gun |
○ |
○ |
||||
|
Charging time (h) |
Fast charging 0.8h (80%), slow charging 13h |
Fast charging 0.8h (80%), slow charging 13h normal temperature (20%~100%) |
||||
|
Chassis system |
Driving form |
Rear-Wheel Drive |
Rear-Wheel Drive |
|||
|
Steering system |
Power steering |
EPS |
EPS |
|||
|
Suspension system |
Front suspension |
McPherson independent suspension |
McPherson independent suspension |
|||
|
Rear suspension |
Leaf spring dependent suspension |
Leaf spring dependent suspension |
||||
|
Braking system |
Front brake type |
Disc |
Disc |
|||
|
Rear brake type |
Drum |
Drum |
||||
|
Braking mode |
Hydraulic brake |
Hydraulic brake |
||||
|
Parking brake type |
Handbrake |
Handbrake |
||||
|
Shift form |
Gear lever |
● |
— |
|||
|
Electronic knob |
— |
● |
||||
|
Tyre |
Tyre specifications |
195R14C 8PR |
195R14C 8PR |
|||
|
Rim material |
Steel |
Steel |
||||
|
Wheel hub cover (4 wheels) |
— |
— |
||||
|
Number of Tyres |
4 |
4 |
||||
|
spare tire |
○(185R14LT 8PR) |
○(185R14LT 8PR) |
||||
|
Door configuration |
Door |
Number of doors |
4 |
4 |
||
|
Side door form |
Manual side sliding door |
Manual side sliding door |
||||
|
Tailgate form |
Door to door |
Door to door |
||||
The New Gonow HM01 new energy logistics vehicle has a body size of 4865 * 1715 * 2060mm, a cargo compartment length, width, and height of 2650 * 1500 * 1350mm, and a wheelbase of 3050mm. The outstanding three dimensions provide HM01 with a large cargo compartment space, with a cargo compartment volume of nearly 6m ³, and a cargo carrying capacity of nearly 1.5 tons. It is equipped with a 41.6kWh lithium iron phosphate battery of Lishen Power. The high endurance version is equipped with a 49.92 kilowatt lithium iron phosphate battery of Lishen Power. It is matched with a permanent magnet synchronous motor with a rated power of 30kW and a peak power of 60kW. The maximum torque is 225N · m, the maximum gradient is 20 °, the maximum speed is 95km/h, the NEDC standard version is 260km, and the high endurance version is 301km. Powerful, economical and practical, it can meet the loading needs of urban green freight delivery users to the greatest extent. Since its launch into the market, it has been deeply loved by distributors and users, and has been repeatedly praised.
