Pure Electric Flatbed Pickup Truck 9.1m³ Cargo Box New Energy

Pure Electric Flatbed Pickup Truck 9.1m³ Cargo Box New Energy

Pure Electric Flatbed Truck

Electric Flatbed Pickup Truck

9.1 m3 Electric Pickup Cargo Truck

Place of Origin:

China

Brand Name:

New Gonow

Model Number:

HM02-Flatbed truck

Contact Us
Request A Quote
Product Details
Product Name:
Pure Electric Flatbed Truck 9.1m³ Cargo Box New Energy Pickup Truck
Overall Dimensions(mm):
5460×1770×2130
Container Size(mm):
3180×1680×360
Wheel Base(mm):
3400
Curb Weight (kg):
1600
Total Mass (kg):
3150
Rated Load Mass (kg):
1420
Endurance Mileage (under Chinese Conditions) (km):
≥190
Motor Type:
Permanent Magnet Synchronous Motor
Battery Power (kWh):
41.93 (Gotion)
Payment & Shipping Terms
Minimum Order Quantity
10
Price
Negotiable
Packaging Details
5460×1770×2130mm
Delivery Time
8 work days
Payment Terms
T/T
Supply Ability
200 units per month
Product Description

Pure Electric Flatbed Truck 9.1m³ Cargo Box New Energy Pickup Truck



Parameters:



Items  EV Pickup Truck

Flatbed truck

Cargo Box

Chassis Truck

Basic parameters

Overall dimensions(mm)

5460×1770×2130

5415×1770×2590

5445×1770×2605

Container size(mm)

3180×1680×360

3150×1680×1720

3180×1680×360

Wheel base(mm)

3400

3400

3400

Curb weight (kg)

1600

1730

1620, 1660

Total mass (kg)

3150

3150

3150

Rated load mass (kg)

1420

1290

1400,1360

Seats

2

2

2

1km maximum speed (km/h)

95

95

95

30min maximum stable speed (km/h)

90

90

90

Maximum gradient

20%

20%

20%

Endurance mileage (under Chinese conditions) (km)

≥190

≥190

≥190

Cargo box volume (m3)

/

≥9m³

≥9m³



Container material

Steel

Steel

Steel



Body type

Non integral body

Non integral body

Non integral body

New energy system

Battery

Battery type

Lithium iron phosphate

Lithium iron phosphate

Lithium iron phosphate

Battery brand

Hengtian

Hengtian

Hengtian

Total battery energy (kWh)

41.93

41.93

41.93

Battery density (Wh/kg)

≥135

≥135

≥135

Battery cooling mode

Natural cooling

Natural cooling

Natural cooling

Electric heating

Drive motor

Motor brand

Oswell

LINCONTROL

Oswell

LINCONTROL

Oswell

LINCONTROL

Motor type

Permanent magnet synchronization

Permanent magnet synchronization

Permanent magnet synchronization

Motor rated/peak power (kW)

30/60

35/70

30/60

35/70

30/60

35/70

Peak torque (N.m)

220

230

220

230

220

230

Motor cooling mode

Liquid cooling

Liquid cooling

Liquid cooling

VCU

VCU brand

HICONICS

LINCONTROL

HICONICS

LINCONTROL

HICONICS

LINCONTROL

Charging mode

Quick charge

Slow charge

Slow charging gun

Charging time (h)

Fast charging 0.8h (80%), slow charging 13h

Fast charging 0.8h (80%), slow charging 13h

Fast charging 0.8h (80%), slow charging 13h

Chassis system

Driving form

Rear-Wheel Drive

Rear-Wheel Drive

Rear-Wheel Drive

Steering system

Power steering

EPS

EPS

EPS

Suspension system

Front suspension

McPherson independent suspension

McPherson independent suspension

McPherson independent suspension

Rear suspension

Leaf spring dependent suspension

Leaf spring dependent suspension

Leaf spring dependent suspension

Braking system

Front brake type

Disc

Disc

Disc

Rear brake type

Drum

Drum

Drum

Braking mode

Hydraulic brake

Hydraulic brake

Hydraulic brake

Parking brake type

Handbrake

Handbrake

Handbrake

Shift form

Gear lever

Electronic knob

Tyre

Tyre specifications

195R14C 8PR

195R14C 8PR

195R14C 8PR

Rim material

Steel

Steel

Steel

Wheel hub cover (4 wheels)

Number of Tyres

4

4

4

spare tire

○(185R14LT 8PR)

○(185R14LT 8PR)

○(185R14LT 8PR)

Door configuration

Door

Number of doors

2

2

2

Cargo box

Side door

/

Right single opening, Optional Double opening

/

tailgate

Single opening from top to bottom

Door to door

Door to door



  • Superior NVH performance, superior to the requirements of similar models.

  • The instrument panel is simple and generous, and there are many convenient storage spaces. The seat design conforms to the human body curve, with strong wrapping and better driving feeling.

  • The key parts of the car body are made of high-strength steel, which can ensure the safety of drivers and passengers while rigidly lifting.

  • The container is made of solid materials and rolled with the latest Baosteel cold-rolled plate. The structure is stable. The body is nearly 5.5 meters long and the rated load is more than 1.4 tons.







Pure Electric Flatbed Pickup Truck 9.1m³ Cargo Box New Energy 0

Pure Electric Flatbed Pickup Truck 9.1m³ Cargo Box New Energy 1



Company Profile



Our company was set up by a group of experts with over 20 years of developing, manufacturing, sales   & marketing in electric vehicles.
Our products are widely exported to European, American, Southeast Asian and Middle East countries, winning high customers, dealers and importers satisfaction.
We provide overseas partners and customers with up-to-date, trend-leading design and well-engineered products and related technical support.
