HM02 Pure Electric Cargo Van 9.1m3 Closed Van Truck

HM02 Pure Electric Cargo Van 9.1m3 Closed Van Truck

HM02 Pure Electric Cargo Van

9.1m3 Closed Van Truck

Pure Electric Cargo Van 9.1m3

Place of Origin:

China

Brand Name:

New Gonow

Model Number:

HM02-Cargo Box

Contact Us
Request A Quote
Product Details
Product Name:
Electric Closed Cargo Van 9.1m³ Closed Container Pure Electric Cargo Van
Overall Dimensions(mm):
5460×1770×2130
Container Size(mm):
3180×1680×360
Wheel Base(mm):
3400
Curb Weight (kg):
1600
Total Mass (kg):
3150
Rated Load Mass (kg):
1420
Seats:
2
Endurance Mileage (under Chinese Conditions) (km):
≥190
Brake Type:
Disc/drum
Body Structure:
Load-bearing Frame Body
Payment & Shipping Terms
Minimum Order Quantity
10
Price
Negotiable
Packaging Details
5460×1770×2130mm
Delivery Time
8 work days
Payment Terms
T/T
Supply Ability
200 units per month
Product Description

Electric Closed Cargo Van 9.1m³ Closed Container Pure Electric Cargo Van​



Configuration Sheet:



Items

Flatbed truck

Cargo Box

Chassis Truck

Basic parameters

Overall dimensions(mm)

5460×1770×2130

5415×1770×2590

5445×1770×2605

Container size(mm)

3180×1680×360

3150×1680×1720

3180×1680×360

Wheel base(mm)

3400

3400

3400

Curb weight (kg)

1600

1730

1620, 1660

Total mass (kg)

3150

3150

3150

Rated load mass (kg)

1420

1290

1400,1360

Seats

2

2

2

1km maximum speed (km/h)

95

95

95

30min maximum stable speed (km/h)

90

90

90

Maximum gradient

20%

20%

20%

Endurance mileage (under Chinese conditions) (km)

≥190

≥190

≥190

Cargo box volume (m3)

/

≥9m³

≥9m³



Container material

Steel

Steel

Steel



Body type

Non integral body

Non integral body

Non integral body

New energy system

Battery

Battery type

Lithium iron phosphate

Lithium iron phosphate

Lithium iron phosphate

Battery brand

Hengtian

Hengtian

Hengtian

Total battery energy (kWh)

41.93

41.93

41.93

Battery density (Wh/kg)

≥135

≥135

≥135

Battery cooling mode

Natural cooling

Natural cooling

Natural cooling

Electric heating

Drive motor

Motor brand

Oswell

LINCONTROL

Oswell

LINCONTROL

Oswell

LINCONTROL

Motor type

Permanent magnet synchronization

Permanent magnet synchronization

Permanent magnet synchronization

Motor rated/peak power (kW)

30/60

35/70

30/60

35/70

30/60

35/70

Peak torque (N.m)

220

230

220

230

220

230

Motor cooling mode

Liquid cooling

Liquid cooling

Liquid cooling

VCU

VCU brand

HICONICS

LINCONTROL

HICONICS

LINCONTROL

HICONICS

LINCONTROL

Charging mode

Quick charge

Slow charge

Slow charging gun

Charging time (h)

Fast charging 0.8h (80%), slow charging 13h

Fast charging 0.8h (80%), slow charging 13h

Fast charging 0.8h (80%), slow charging 13h

Chassis system

Driving form

Rear-Wheel Drive

Rear-Wheel Drive

Rear-Wheel Drive

Steering system

Power steering

EPS

EPS

EPS

Suspension system

Front suspension

McPherson independent suspension

McPherson independent suspension

McPherson independent suspension

Rear suspension

Leaf spring dependent suspension

Leaf spring dependent suspension

Leaf spring dependent suspension

Braking system

Front brake type

Disc

Disc

Disc

Rear brake type

Drum

Drum

Drum

Braking mode

Hydraulic brake

Hydraulic brake

Hydraulic brake

Parking brake type

Handbrake

Handbrake

Handbrake

Shift form

Gear lever

Electronic knob

Tyre

Tyre specifications

195R14C 8PR

195R14C 8PR

195R14C 8PR

Rim material

Steel

Steel

Steel

Wheel hub cover (4 wheels)

Number of Tyres

4

4

4

spare tire

○(185R14LT 8PR)

○(185R14LT 8PR)

○(185R14LT 8PR)

Door configuration

Door

Number of doors

2

2

2

Cargo box

Side door

/

Right single opening, Optional Double opening

/

tailgate

Single opening from top to bottom

Door to door

Door to door





The whole vehicle is equipped with Gotion 41.93kWh high safety lithium iron phosphate battery, with a driving range of more than 193km under multiple working conditions, and an ultra durable stability of 5 years and 200,000 km; Embed the risk identification and management function of the smart BMS of the battery cell, match the stable and reliable charging and discharging safety management strategy, and protect the high-strength alloy shell to ensure the safety of customers' electricity use in multiple dimensions; Refined energy consumption design based on environmental protection and energy conservation.





HM02 Pure Electric Cargo Van 9.1m3 Closed Van Truck 0

HM02 Pure Electric Cargo Van 9.1m3 Closed Van Truck 1



Company Profile



Our company was set up by a group of experts with over 20 years of developing, manufacturing, sales   & marketing in electric vehicles.
Our products are widely exported to European, American, Southeast Asian and Middle East countries, winning high customers, dealers and importers satisfaction.
We provide overseas partners and customers with up-to-date, trend-leading design and well-engineered products and related technical support.



HM02 Pure Electric Cargo Van 9.1m3 Closed Van Truck 2
