Place of Origin:
China
Brand Name:
New Gonow
Model Number:
HM02-Cargo Box
Mini Truck High Speed New Engergy Pickup Truck Large Cargo Container Long Range Pickup
Product Configuration:
|
Items |
Flatbed truck |
Cargo Box |
Chassis Truck |
|||||
|
Basic parameters |
Overall dimensions(mm) |
5460×1770×2130 |
5415×1770×2590 |
5445×1770×2605 |
||||
|
Container size(mm) |
3180×1680×360 |
3150×1680×1720 |
3180×1680×360 |
|||||
|
Wheel base(mm) |
3400 |
3400 |
3400 |
|||||
|
Curb weight (kg) |
1600 |
1730 |
1620, 1660 |
|||||
|
Total mass (kg) |
3150 |
3150 |
3150 |
|||||
|
Rated load mass (kg) |
1420 |
1290 |
1400,1360 |
|||||
|
Seats |
2 |
2 |
2 |
|||||
|
1km maximum speed (km/h) |
95 |
95 |
95 |
|||||
|
30min maximum stable speed (km/h) |
90 |
90 |
90 |
|||||
|
Maximum gradient |
20% |
20% |
20% |
|||||
|
Endurance mileage (under Chinese conditions) (km) |
≥190 |
≥190 |
≥190 |
|||||
|
Cargo box volume (m3) |
/ |
≥9m³ |
≥9m³ |
|||||
|
|
Container material |
Steel |
Steel |
Steel |
||||
|
|
Body type |
Non integral body |
Non integral body |
Non integral body |
||||
|
New energy system |
Battery |
Battery type |
Lithium iron phosphate |
Lithium iron phosphate |
Lithium iron phosphate |
|||
|
Battery brand |
Hengtian |
Hengtian |
Hengtian |
|||||
|
Total battery energy (kWh) |
41.93 |
41.93 |
41.93 |
|||||
|
Battery density (Wh/kg) |
≥135 |
≥135 |
≥135 |
|||||
|
Battery cooling mode |
Natural cooling |
Natural cooling |
Natural cooling |
|||||
|
Electric heating |
● |
● |
● |
|||||
|
Drive motor |
Motor brand |
Oswell |
LINCONTROL |
Oswell |
LINCONTROL |
Oswell |
LINCONTROL |
|
|
Motor type |
Permanent magnet synchronization |
Permanent magnet synchronization |
Permanent magnet synchronization |
|||||
|
Motor rated/peak power (kW) |
30/60 |
35/70 |
30/60 |
35/70 |
30/60 |
35/70 |
||
|
Peak torque (N.m) |
220 |
230 |
220 |
230 |
220 |
230 |
||
|
Motor cooling mode |
Liquid cooling |
Liquid cooling |
Liquid cooling |
|||||
|
VCU |
VCU brand |
HICONICS |
LINCONTROL |
HICONICS |
LINCONTROL |
HICONICS |
LINCONTROL |
|
|
Charging mode |
Quick charge |
● |
● |
● |
||||
|
Slow charge |
● |
● |
● |
|||||
|
Slow charging gun |
○ |
○ |
○ |
|||||
|
Charging time (h) |
Fast charging 0.8h (80%), slow charging 13h |
Fast charging 0.8h (80%), slow charging 13h |
Fast charging 0.8h (80%), slow charging 13h |
|||||
|
Chassis system |
Driving form |
Rear-Wheel Drive |
Rear-Wheel Drive |
Rear-Wheel Drive |
||||
|
Steering system |
Power steering |
EPS |
EPS |
EPS |
||||
|
Suspension system |
Front suspension |
McPherson independent suspension |
McPherson independent suspension |
McPherson independent suspension |
||||
|
Rear suspension |
Leaf spring dependent suspension |
Leaf spring dependent suspension |
Leaf spring dependent suspension |
|||||
|
Braking system |
Front brake type |
Disc |
Disc |
Disc |
||||
|
Rear brake type |
Drum |
Drum |
Drum |
|||||
|
Braking mode |
Hydraulic brake |
Hydraulic brake |
Hydraulic brake |
|||||
|
Parking brake type |
Handbrake |
Handbrake |
Handbrake |
|||||
|
Shift form |
Gear lever |
— |
— |
— |
||||
|
Electronic knob |
● |
● |
● |
|||||
|
Tyre |
Tyre specifications |
195R14C 8PR |
195R14C 8PR |
195R14C 8PR |
||||
|
Rim material |
Steel |
Steel |
Steel |
|||||
|
Wheel hub cover (4 wheels) |
— |
— |
— |
|||||
|
Number of Tyres |
4 |
4 |
4 |
|||||
|
spare tire |
○(185R14LT 8PR) |
○(185R14LT 8PR) |
○(185R14LT 8PR) |
|||||
|
Door configuration |
Door |
Number of doors |
2 |
2 |
2 |
|||
|
Cargo box |
Side door |
/ |
Right single opening, Optional Double opening |
/ |
||||
|
tailgate |
Single opening from top to bottom |
Door to door |
Door to door |
|||||
Product highlights - safety
It has UDS diagnostic function and can take safe fault handling measures in case of vehicle fault; The remote vehicle locking function can realize the remote control of vehicles, and can realize the management of operating vehicles without leaving the home, and has the anti-theft effect.
The vehicle charging system adopts a four in one refined design scheme. The highly integrated PCB brings higher transmission efficiency. The smaller volume of the integrated assembly has higher reliability. While achieving high efficiency and lightweight level, the EMC effect and electrical safety of the vehicle and the system have been greatly improved.
Company Profile
Our company was set up by a group of experts with over 20 years of developing, manufacturing, sales & marketing in electric vehicles.
Our products are widely exported to European, American, Southeast Asian and Middle East countries, winning high customers, dealers and importers satisfaction.
We provide overseas partners and customers with up-to-date, trend-leading design and well-engineered products and related technical support.
