Place of Origin:
China
Brand Name:
New Gonow
Model Number:
HM02-Cargo Box
Pure Electric Logistics Vehicle for Urban and City Use Electric Cargo Van for Personal or Small Business
Details:
|
Items |
Flatbed truck |
Cargo Box |
Chassis Truck |
|||||
|
Basic parameters |
Overall dimensions(mm) |
5460×1770×2130 |
5415×1770×2590 |
5445×1770×2605 |
||||
|
Container size(mm) |
3180×1680×360 |
3150×1680×1720 |
3180×1680×360 |
|||||
|
Wheel base(mm) |
3400 |
3400 |
3400 |
|||||
|
Curb weight (kg) |
1600 |
1730 |
1620, 1660 |
|||||
|
Total mass (kg) |
3150 |
3150 |
3150 |
|||||
|
Rated load mass (kg) |
1420 |
1290 |
1400,1360 |
|||||
|
Seats |
2 |
2 |
2 |
|||||
|
1km maximum speed (km/h) |
95 |
95 |
95 |
|||||
|
30min maximum stable speed (km/h) |
90 |
90 |
90 |
|||||
|
Maximum gradient |
20% |
20% |
20% |
|||||
|
Endurance mileage (under Chinese conditions) (km) |
≥190 |
≥190 |
≥190 |
|||||
|
Cargo box volume (m3) |
/ |
≥9m³ |
≥9m³ |
|||||
|
|
Container material |
Steel |
Steel |
Steel |
||||
|
|
Body type |
Non integral body |
Non integral body |
Non integral body |
||||
|
New energy system |
Battery |
Battery type |
Lithium iron phosphate |
Lithium iron phosphate |
Lithium iron phosphate |
|||
|
Battery brand |
Hengtian |
Hengtian |
Hengtian |
|||||
|
Total battery energy (kWh) |
41.93 |
41.93 |
41.93 |
|||||
|
Battery density (Wh/kg) |
≥135 |
≥135 |
≥135 |
|||||
|
Battery cooling mode |
Natural cooling |
Natural cooling |
Natural cooling |
|||||
|
Electric heating |
● |
● |
● |
|||||
|
Drive motor |
Motor brand |
Oswell |
LINCONTROL |
Oswell |
LINCONTROL |
Oswell |
LINCONTROL |
|
|
Motor type |
Permanent magnet synchronization |
Permanent magnet synchronization |
Permanent magnet synchronization |
|||||
|
Motor rated/peak power (kW) |
30/60 |
35/70 |
30/60 |
35/70 |
30/60 |
35/70 |
||
|
Peak torque (N.m) |
220 |
230 |
220 |
230 |
220 |
230 |
||
|
Motor cooling mode |
Liquid cooling |
Liquid cooling |
Liquid cooling |
|||||
|
VCU |
VCU brand |
HICONICS |
LINCONTROL |
HICONICS |
LINCONTROL |
HICONICS |
LINCONTROL |
|
|
Charging mode |
Quick charge |
● |
● |
● |
||||
|
Slow charge |
● |
● |
● |
|||||
|
Slow charging gun |
○ |
○ |
○ |
|||||
|
Charging time (h) |
Fast charging 0.8h (80%), slow charging 13h |
Fast charging 0.8h (80%), slow charging 13h |
Fast charging 0.8h (80%), slow charging 13h |
|||||
|
Chassis system |
Driving form |
Rear-Wheel Drive |
Rear-Wheel Drive |
Rear-Wheel Drive |
||||
|
Steering system |
Power steering |
EPS |
EPS |
EPS |
||||
|
Suspension system |
Front suspension |
McPherson independent suspension |
McPherson independent suspension |
McPherson independent suspension |
||||
|
Rear suspension |
Leaf spring dependent suspension |
Leaf spring dependent suspension |
Leaf spring dependent suspension |
|||||
|
Braking system |
Front brake type |
Disc |
Disc |
Disc |
||||
|
Rear brake type |
Drum |
Drum |
Drum |
|||||
|
Braking mode |
Hydraulic brake |
Hydraulic brake |
Hydraulic brake |
|||||
|
Parking brake type |
Handbrake |
Handbrake |
Handbrake |
|||||
|
Shift form |
Gear lever |
— |
— |
— |
||||
|
Electronic knob |
● |
● |
● |
|||||
|
Tyre |
Tyre specifications |
195R14C 8PR |
195R14C 8PR |
195R14C 8PR |
||||
|
Rim material |
Steel |
Steel |
Steel |
|||||
|
Wheel hub cover (4 wheels) |
— |
— |
— |
|||||
|
Number of Tyres |
4 |
4 |
4 |
|||||
|
spare tire |
○(185R14LT 8PR) |
○(185R14LT 8PR) |
○(185R14LT 8PR) |
|||||
|
Door configuration |
Door |
Number of doors |
2 |
2 |
2 |
|||
|
Cargo box |
Side door |
/ |
Right single opening, Optional Double opening |
/ |
||||
|
tailgate |
Single opening from top to bottom |
Door to door |
Door to door |
|||||
From the front face, the HM02 has a silver chrome strip running through the entire front face and connecting with the headlight groups on both sides. With a silver logo on a black base, the overall appearance is highly recognizable.
The front grille below the logo is trapezoidal in shape and adopts a long cylindrical hollow design. A row of rectangular air intakes are also added in the middle of the front bumper below, which can better cool the bottom battery and make the vehicle safer to drive. The head lamp set adopts a triangle like design, with turn signal, low beam, high beam and daytime driving lamp as the lamp eyebrow integrated inside, which makes it sharp and stylish. The tire size of HM02 is 195R14C 8PR, with a front wheel track width of 1555mm and a rear wheel track width of 1450mm. The front wheels use disc brakes, while the rear wheels use drum brakes.
