Place of Origin:
China
Brand Name:
Kunming passenger car
Model Number:
Classic
RWD 2-seater 4KW or 5KW Pickup Trucks Classic Model Electric Pickup 40kmh Pickman
Pickup Truck Specifications:
No. |
Model name |
Classic |
Classic |
1 |
Model ID |
YNKY1131D4 |
YNKY1131D5 |
2 |
Vehicle status |
72V 4KW |
72V 5KW |
3 |
Right hand drive |
○ |
○ |
4 |
Length × Width × Height (mm) |
3475×1375×1550 |
3475×1375×1550 |
5 |
Container internal dimensions |
1620X1245X300 |
1620X1245X300 |
6 |
Wheelbase (mm) |
2315 |
2315 |
7 |
Front track (mm) |
1195 |
1195 |
8 |
Rear track (mm) |
1185 |
1185 |
9 |
Front suspension (mm) |
455 |
455 |
10 |
Rear suspention (mm) |
705 |
705 |
11 |
Curb weight (kg) |
710 |
710 |
12 |
Load quality (kg) |
500 |
500 |
13 |
Seats No. |
2 |
2 |
14 |
Gross weight (kg) |
1340 |
1340 |
15 |
Performance parameters |
|
|
16 |
Max speed (km/h) |
40 |
40 |
17 |
Acceleration time s (0-40km) |
15 |
15 |
18 |
Max grade |
0.25 |
0.25 |
19 |
Min turning diameter (m) |
≤9 |
≤9 |
20 |
Maximum angle |
36.3(outer wheel)/42(inner wheel) |
36.3(outer wheel)/42(inner wheel) |
21 |
Approach angle (°) |
≥55 |
≥55 |
22 |
Departure angle (°) |
≥35 |
≥35 |
23 |
Bauchfreiheit (mm, no load) |
≥150 |
≥150 |
24 |
Body structure |
|
|
25 |
Cab |
Integral sheet metal |
Integral sheet metal |
26 |
Tube doors |
- |
- |
27 |
Cargo box (bed) |
Triple folding gate |
Triple folding gate |
28 |
Battery/motor parameters |
|
|
29 |
Battery type |
Maintenance-free |
Maintenance-free |
. |
Battery specification(V/Ah) |
72V ,100Ah |
72V ,100Ah |
31 |
Battery optional |
○ 105Ah LFP |
○ 105Ah LFP |
32 |
Lithium electric heating plate |
○ |
○ |
33 |
Driving mileage (no load) (km) |
≥120 |
≥120 |
34 |
220V charging plug |
● |
● |
35 |
110~220V charging plug (wide voltage) |
○ |
○ |
36 |
Charging time (20%-100%) (h) |
8~10 |
8~10 |
37 |
Motor type |
||
38 |
Rated power (kW) |
4KW |
5KW |
39 |
Chassis/Wheel Braking |
|
|
40 |
Drive form |
RWD |
RWD |
41 |
Front suspension |
Double wishbone coil spring independent suspension |
Double wishbone coil spring independent suspension |
42 |
Rear suspension |
Vertical leaf spring (5 pieces) |
Vertical leaf spring (5 pieces) |
43 |
Drive axle |
Integral (speed ratio 12.76) |
Integral (speed ratio 12.76) |
44 |
Front brake |
Disc |
Disc |
45 |
Rear brake |
Drum |
Drum |
46 |
Rim |
12X4B(steel)● |
12X4B(steel)● |
47 |
Tire |
145 R12LT(radial tire)● |
145 R12LT(radial tire)● |
48 |
power-assisted steering |
○ |
○ |
49 |
Brake assist |
● |
● |
50 |
Inside/outside configuration |
|
|
51 |
Door lock |
Manual |
Manual |
52 |
Window |
Manual |
Manual |
53 |
Front Seat |
Primary/Secondary Independent Seats |
Primary/Secondary Independent Seats |
54 |
Rear seat |
- |
- |
55 |
Interior rear view mirror |
● |
● |
56 |
Instrument |
Metric● |
Metric● |
57 |
AVS Sound Module |
○ |
○ |
58 |
Side retro reflector |
● |
● |
59 |
Red reflective stickers |
○ |
○ |
60 |
Seat belt |
● |
● |
61 |
Seat belt certification |
DOT ● |
DOT ● |
62 |
Reverse image |
● |
● |
63 |
Mp5 |
7“MP5● |
7“MP5● |
64 |
Charger plug |
China standard ● |
China standard ● |
65 |
VIN |
● right/○ left |
● right/○ left |
66 |
Spray wax |
○ |
○ |
67 |
Swatches |
● |
● |
68 |
Rubber Liner |
○ |
○ |
|
"-" indicates that this configuration is not available. "○" represents optional items, which need to be selected and explained; ● Indicates the standard configuration item. |
Wide applicability
Flexible and diverse functions, wide applicability, compact structure, and take up few storing space
High driving comfort
Able to easily handle various scenarios
Easy to use
Good passability
More cost-effective
Fast charging time 8 hours, slow charging time 10 hours
More photos:
Qualifications and Certificates:
and
and
2. Equipment: A series of advanced production equipment, including stamping equipment, welding equipment, spraying equipment, assembly equipment, etc.
