Place of Origin:
China
Brand Name:
New Gonow
Model Number:
HU01
7.2m³ Electric Cargo Van 90km/h Pure Electric Logistics Market Transportation Truck
Product specifications:
Items |
HU01 (7m3 Logistics vehicle)- standard model |
HU01 (7m3 Logistics vehicle)- Logistics links model |
|||
Basic parameters |
Overall dimensions |
Length(mm) |
5428 |
||
Width(mm) |
1780 |
||||
Height(mm) |
1950 |
||||
Front suspension(mm) |
798 |
||||
Rear suspension(mm) |
1280 |
||||
Wheel base(mm) |
3350 |
||||
Front track width(mm) |
1558 |
||||
Rear track width(mm) |
1565 |
||||
Container size |
Internal length(mm) |
3010 |
|||
Inside width(mm) |
1710 |
||||
Inner height(mm) |
1400 |
||||
Container volume(m³) |
7.2 |
||||
Quality parameters |
Unladen mass (kg) |
1445 |
1470 |
||
Servicing front axle load (kg) |
850 |
890 |
|||
Rear servicing axle load (kg) |
595 |
580 |
|||
Rated load mass (kg) |
1235 |
1210 |
|||
Full load mass (kg) |
2810 |
||||
Full load front axle load (kg) |
1150 |
||||
Axle load after full load (kg) |
1660 |
||||
Performance parameters |
30min maximum stable speed (km/h) |
≥85 |
|||
1km maximum instantaneous speed (km/h) |
≥90 |
||||
0~50km/h acceleration time (s) |
≤6 |
||||
50~80km/h acceleration time (s) |
≤10 |
||||
Maximum gradient |
≥20% |
||||
Energy consumption (Ekg) (Wh/km. kg) |
≤0.28 |
||||
New energy system |
Battery |
Battery type |
Lithium iron phosphate |
||
Battery manufacturer |
Hengtian Gotion |
CATL |
|||
Power (kWh) |
41.93 |
50.23 |
|||
Mileage Range |
220 |
305 |
|||
Voltage level (V) |
332.8 |
334.88 |
|||
Energy density (Wh/kg) |
≥135 |
||||
Battery pack cooling mode |
Natural cooling |
||||
Battery electric heating |
● |
||||
Motor |
Motor type |
Permanent magnet synchronous motor |
|||
Motor rated/peak power (kW) |
35/70 |
||||
Motor rated/peak torque (N.m) |
80/190 |
||||
Motor rated/peak speed (rpm) |
4178/10000 |
||||
Motor cooling mode |
water-cooling |
||||
Charging mode |
Quick charge |
●(China standard) |
|||
Slow charge |
●(China standard) |
||||
Slow charging gun |
○(Portable AC charging gun - China standard) |
||||
Fast charging time (h) (30%~80%) |
≤1 |
||||
Slow charging time (h) (20%~100%) |
≤13.5 |
||||
Chassis system |
Driving form |
FF |
|||
Reducer speed ratio |
10.589 |
||||
Steering system |
Steering gear |
Rack and pinion type |
|||
Power steering |
EPS |
||||
Steering column adjustment |
Non adjustable |
||||
Suspension system |
Front suspension |
McPherson independent suspension |
|||
Rear suspension |
Leaf spring dependent suspension |
||||
Braking system |
Front brake type |
Disc type |
|||
Rear brake type |
Drum type |
||||
Braking mode |
Hydraulic brake |
||||
Parking brake type |
Handbrake |
||||
Shift form |
Gear lever |
— |
|||
Electronic knob |
● |
||||
Tyre |
Tire type |
185/65R15LT 12PR |
|||
Rim model |
15X5.5J |
||||
Rim material |
Steel |
||||
Number of tires |
4 |
||||
Body system |
Body structure |
Load bearing frame body |
|||
Door |
Tailgate |
Asymmetric split door |
|||
Side door |
Right side lift door |
||||
Security Configuration |
Safety air bag |
Driver/co driver |
—/— |
||
Seat belt (driver) |
Ordinary three-point safety belt |
● |
|||
Adjustable seat belt height |
— |
||||
Prompt for unfastened seat belt |
● |
||||
Seat belt (co driver) |
Ordinary three-point safety belt |
● |
|||
Adjustable seat belt height |
— |
||||
Prompt for unfastened seat belt |
— |
||||
Central locking |
Interior central locking |
● |
|||
Automatic locking of driving |
● |
||||
Radar/image |
Front parking radar |
— |
|||
Rear reversing radar |
● |
||||
Blind area monitoring |
— |
||||
Key |
Mechanical key |
● |
|||
Remote key |
● |
||||
Door open reminder |
● |
||||
Low speed alarm |
● |
||||
Remote monitoring |
● |
||||
ABS |
● |
||||
EBD |
● |
||||
Motor anti-theft function |
— |
||||
Tire pressure monitoring device |
— |
||||
Tips for fatigue driving |
— |
||||
Lane departure warning system |
— |
||||
External configuration |
Front bumper |
Up white and down black |
|||
Rear bumper |
Black |
||||
Front grille |
Nets |
||||
Mudguard |
Front wheel fender |
● |
|||
Rear wheel fender |
● |
||||
Logo |
Front logo |
● |
|||
Character mark |
● |
||||
Rear logo |
● |
||||
Reflective stickers/Reflectors |
Reflective sticker |
||||
Internal configuration |
Steering wheel |
Steering wheel material |
Foaming |
||
Steering wheel adjustment (manual) |
— |
||||
Instrument cluster |
Mechanical combination instrument |
● |
|||
Cruise |
Cruise control |
— |
|||
Adaptive Cruise |
— |
||||
Instrument panel |
Glove box |
●(External) |
|||
ashtray |
— |
||||
Ignition |
— |
||||
Water cup bracket |
— |
||||
Card slot |
— |
||||
12V power supply (USB) |
● |
||||
220V power supply |
— |
||||
Sun visor (without vanity mirror) |
● |
||||
Ceiling handle |
— |
||||
Handle for boarding |
— |
||||
Handrail for boarding |
— |
||||
Compartment partition with glass |
● |
||||
tachograph |
— |
||||
ETC |
○ |
||||
Fire Extinguisher |
● |
||||
Triangle warning board |
● |
||||
Reflective vest |
● |
||||
On-board tools |
● |
||||
Tyre mending device |
● |
||||
lifting jack |
— |
||||
Cargo box configuration |
Ceiling |
— |
|||
Left side guard |
○(aluminum, half wrapped) |
||||
Right side guard |
○(aluminum, half wrapped) |
||||
Side door interior trim panel |
● |
||||
Split door interior trim panel |
● |
||||
Seat configuration |
Seats |
2 |
|||
Driver |
Seat material |
Weaving |
|||
Seat fore and aft adjustment |
● |
||||
Seat height adjustment |
— |
||||
Seat back adjustment |
● |
||||
Adjustable head restraints |
Separate head restraint |
||||
Driver exit prompt |
● |
||||
Co driver |
Seat material |
Weaving |
|||
Seat fore and aft adjustment |
● |
||||
Seat height adjustment |
— |
||||
Seat back adjustment |
● |
||||
Adjustable head restraints |
separate head restraint |
||||
Multimedia configuration |
AM/FM |
○ |
|||
MP3 |
○ |
||||
USB |
○ |
||||
Number of speakers |
○(2) |
||||
Light configuration |
High beam lamp |
● |
|||
Low beam lamp |
● |
||||
Front fog lamp |
— |
||||
Rear fog lamp |
● |
||||
Daytime driving light |
— |
||||
Cab roof lamp |
● |
||||
License plate lamp |
● |
||||
Side turn lamp |
●(Integrated exterior rear-view mirror) |
||||
Clearance lamp |
— |
||||
High mounted brake lamp |
● |
||||
Cargo box lamp |
● |
||||
Low beam lamp automatically turns on |
— |
||||
Headlamp height adjustment |
● |
||||
Glass/rear-view mirror |
Window |
Power windows |
● |
||
Rearview mirror |
Interior rearview mirror |
— |
|||
Electric adjustment of rearview mirror |
●(Electric adjustment, manual folding) |
||||
Front wiper |
Boned front wiper |
● |
|||
Boneless front wiper |
— |
||||
Air conditioning system |
Manual air conditioner |
● |
|||
Automatic air conditioning |
— |
||||
Other configurations |
On board OBD system |
● |
|||
Remote locking function |
● |
||||
Trailer hook |
●(Front) |
||||
●: Standard configuration ○: Optional -: Not configured |
More pictures:
Company Profile
Our company was set up by a group of experts with over 20 years of developing, manufacturing, sales & marketing in electric vehicles.
Our products are widely exported to European, American, Southeast Asian and Middle East countries, winning high customers, dealers and importers satisfaction.
We provide overseas partners and customers with up-to-date, trend-leading design and well-engineered products and related technical support.
