Place of Origin:
China
Brand Name:
New Gonow
Model Number:
HM02-Flatbed truck
Safe Reliable EV Pickup Truck Lower Cost Higher Economic Efficiency New Energy Logistics Vehicle
Product Configuration
|
EV Pickup Truck |
Flatbed truck |
Cargo Box |
Chassis Truck |
|||||
|
Basic parameters |
Overall dimensions(mm) |
5460×1770×2130 |
5415×1770×2590 |
5445×1770×2605 |
||||
|
Container size(mm) |
3180×1680×360 |
3150×1680×1720 |
3180×1680×360 |
|||||
|
Wheel base(mm) |
3400 |
3400 |
3400 |
|||||
|
Curb weight (kg) |
1600 |
1730 |
1620, 1660 |
|||||
|
Total mass (kg) |
3150 |
3150 |
3150 |
|||||
|
Rated load mass (kg) |
1420 |
1290 |
1400,1360 |
|||||
|
Seats |
2 |
2 |
2 |
|||||
|
1km maximum speed (km/h) |
95 |
95 |
95 |
|||||
|
30min maximum stable speed (km/h) |
90 |
90 |
90 |
|||||
|
Maximum gradient |
20% |
20% |
20% |
|||||
|
Endurance mileage (under Chinese conditions) (km) |
≥190 |
≥190 |
≥190 |
|||||
|
Cargo box volume (m3) |
/ |
≥9m³ |
≥9m³ |
|||||
|
|
Container material |
Steel |
Steel |
Steel |
||||
|
|
Body type |
Non integral body |
Non integral body |
Non integral body |
||||
|
New energy system |
Battery |
Battery type |
Lithium iron phosphate |
Lithium iron phosphate |
Lithium iron phosphate |
|||
|
Battery brand |
Hengtian |
Hengtian |
Hengtian |
|||||
|
Total battery energy (kWh) |
41.93 |
41.93 |
41.93 |
|||||
|
Battery density (Wh/kg) |
≥135 |
≥135 |
≥135 |
|||||
|
Battery cooling mode |
Natural cooling |
Natural cooling |
Natural cooling |
|||||
|
Electric heating |
● |
● |
● |
|||||
|
Drive motor |
Motor brand |
Oswell |
LINCONTROL |
Oswell |
LINCONTROL |
Oswell |
LINCONTROL |
|
|
Motor type |
Permanent magnet synchronization |
Permanent magnet synchronization |
Permanent magnet synchronization |
|||||
|
Motor rated/peak power (kW) |
30/60 |
35/70 |
30/60 |
35/70 |
30/60 |
35/70 |
||
|
Peak torque (N.m) |
220 |
230 |
220 |
230 |
220 |
230 |
||
|
Motor cooling mode |
Liquid cooling |
Liquid cooling |
Liquid cooling |
|||||
|
VCU |
VCU brand |
HICONICS |
LINCONTROL |
HICONICS |
LINCONTROL |
HICONICS |
LINCONTROL |
|
|
Charging mode |
Quick charge |
● |
● |
● |
||||
|
Slow charge |
● |
● |
● |
|||||
|
Slow charging gun |
○ |
○ |
○ |
|||||
|
Charging time (h) |
Fast charging 0.8h (80%), slow charging 13h |
Fast charging 0.8h (80%), slow charging 13h |
Fast charging 0.8h (80%), slow charging 13h |
|||||
|
Chassis system |
Driving form |
Rear-Wheel Drive |
Rear-Wheel Drive |
Rear-Wheel Drive |
||||
|
Steering system |
Power steering |
EPS |
EPS |
EPS |
||||
|
Suspension system |
Front suspension |
McPherson independent suspension |
McPherson independent suspension |
McPherson independent suspension |
||||
|
Rear suspension |
Leaf spring dependent suspension |
Leaf spring dependent suspension |
Leaf spring dependent suspension |
|||||
|
Braking system |
Front brake type |
Disc |
Disc |
Disc |
||||
|
Rear brake type |
Drum |
Drum |
Drum |
|||||
|
Braking mode |
Hydraulic brake |
Hydraulic brake |
Hydraulic brake |
|||||
|
Parking brake type |
Handbrake |
Handbrake |
Handbrake |
|||||
|
Shift form |
Gear lever |
— |
— |
— |
||||
|
Electronic knob |
● |
● |
● |
|||||
|
Tyre |
Tyre specifications |
195R14C 8PR |
195R14C 8PR |
195R14C 8PR |
||||
|
Rim material |
Steel |
Steel |
Steel |
|||||
|
Wheel hub cover (4 wheels) |
— |
— |
— |
|||||
|
Number of Tyres |
4 |
4 |
4 |
|||||
|
spare tire |
○(185R14LT 8PR) |
○(185R14LT 8PR) |
○(185R14LT 8PR) |
|||||
|
Door configuration |
Door |
Number of doors |
2 |
2 |
2 |
|||
|
Cargo box |
Side door |
/ |
Right single opening, Optional Double opening |
/ |
||||
|
tailgate |
Single opening from top to bottom |
Door to door |
Door to door |
|||||
HM02 is positioned as an ultra wide body micro van, with super large space and strong carrying capacity, which can fully meet the more diverse needs of market users. It can be applied to more diverse logistics scenarios such as daily necessities, decoration and building materials, and supermarket delivery.
The size of HM02 is at the leading level in its class, reaching 5415×1770×2590mm, container size 3150×1680×1720mm, wheelbase 3400mm, with a capacity of over 9m for box models; With a load capacity of around 1.2 tons, it is among the best in terms of capacity and cargo carrying capacity among micro vans. It not only allows for smooth entry and exit of underground warehouses and streets, but also accommodates oversized goods and more combinations of goods, meeting more usage scenarios and easily achieving good profits.
Company Profile
Our company was set up by a group of experts with over 20 years of developing, manufacturing, sales & marketing in electric vehicles.
Our products are widely exported to European, American, Southeast Asian and Middle East countries, winning high customers, dealers and importers satisfaction.
We provide overseas partners and customers with up-to-date, trend-leading design and well-engineered products and related technical support.
