Place of Origin:
EEC
Brand Name:
KUNKE
Model Number:
Adventure
High Speed EV Pickup Truck Pickman Electric Pickup Truck Adult Vehicle EV RWD Pickup 120km
EV Pickup Truck Parameters:
|
Parameters |
|
|
Model name |
Adventure |
|
Model ID |
YNKY1137D5 |
|
Vehicle status |
72V 5KW |
|
Right hand drive |
○ |
|
Length × Width × Height (mm) |
3475×1375×1620 |
|
Container internal dimensions |
1620X1245X300 |
|
Wheelbase (mm) |
2315 |
|
Front track (mm) |
1195 |
|
Rear track (mm) |
1185 |
|
Front suspension (mm) |
455 |
|
Rear suspention (mm) |
705 |
|
Curb weight (kg) |
720 |
|
Load quality (kg) |
500 |
|
Seats No. |
2 |
|
Gross weight (kg) |
1350 |
|
Performance parameters |
|
|
Max speed (km/h) |
40 |
|
Acceleration time s (0-40km) |
15 |
|
Max grade |
0.25 |
|
Min turning diameter (m) |
≤9 |
|
Maximum angle |
36.3(outer wheel)/42(inner wheel) |
|
Approach angle (°) |
≥65 |
|
Departure angle (°) |
≥41 |
|
Bauchfreiheit (mm, no load) |
≥170 |
|
Body structure |
|
|
Cab |
Integral sheet metal |
|
Tube doors |
○ |
|
Cargo box (bed) |
Triple folding gate |
|
Battery/motor parameters |
|
|
Battery type |
Maintenance-free |
|
Battery specification(V/Ah) |
72V ,100Ah |
|
Battery optional |
○ 105Ah LFP |
|
Lithium electric heating plate |
○ |
|
Driving mileage (no load) (km) |
≥120 |
|
220V charging plug |
● |
|
110~220V charging plug (wide voltage) |
○ |
|
Charging time (20%-100%) (h) |
8~10 |
|
Motor type |
|
|
Rated power (kW) |
5KW |
|
Chassis/Wheel Braking |
|
|
Drive form |
RWD |
|
Front suspension |
Double wishbone coil spring independent suspension |
|
Rear suspension |
Vertical leaf spring (5 pieces) |
|
Drive axle |
Integral (speed ratio 12.76) |
|
Front brake |
Disc |
|
Rear brake |
Drum |
|
Rim |
12×3.75(aluminum)● |
|
Tire |
5.00-12ULT (dirt tires)● |
|
power-assisted steering |
● |
|
Brake assist |
● |
|
Inside/outside configuration |
|
|
"-" indicates that this configuration is not available. "○" represents optional items, which need to be selected and explained; ● Indicates the standard configuration item. |
|
